SmokeGuard®

Lift doors with integrated smoke protection system

After the catastrophic fire in 2017 in London's Grenfell Tower there has been an ever-increasing demand for "smoke-tight" lift doors. On the one hand, such door systems cannot be realised due to design factors and on the other hand there are standards- related factors that also impede this.

To prevent smoke  spreading through the lift doors, through the lift shaft and into other floors, there is only one possibility: The landing doors must be combined with a smoke-tight seal that does not impair the fire-certification criteria.

MEILLER has developed the solution with SmokeGuard®: Landing doors, fire-tested per EN 81-58, are combined with a smoke protection curtain from a renowned manufacturer.

An accredited fire institute has tested this com- bination and confirmed that the installation of the smoke protection curtain on the fire-tested landing door in no way affects the fire resistance.

In practice, a number of prerequisites must be observed when ordering the landing doors: EvoN installation type (niche installation), frame width 100 mm etc. The frame and sill are then pre- pared by MEILLER for the installation of the smoke protection curtain. The curtain itself is installed at the construction site on the frame and sill of the landing door.

Thanks to a universally applicable control system for the smoke protection curtain (static or dynamic fire control, fire alarm control panel or others), the triggering of the smoke protection curtain can be integrated into any conceivable scenario. This must be implemented accordingly by the lift manufacturer or the controller manufacturer.

­­

Quality features SmokeGuard®

  • Landing door with smoke-proof  protective curtain for sealing off the  lift car and lift shaft floor by floor
  • Guarantee of fire-protection criteria  with compliance with EN 81-58 resp.  ISO 3008
  • Combination of door and smoke- protection curtain tested and approved  by accredited fire institute
  • Smoke-protection curtain per  DIN EN 12101-1, smoke hoods
  • No impairment of the performance  with regard to the power, speed,  noise level or energy

SmokeGuard® is available for all MEILLER sliding doors with steel door panels (double skin) or vision panels, up to a max. door height of 3000 mm (vision panel max. height: 2445 mm).

SmokeGuard® is thus the first solution on the mar- ket for smoke-proof lift landing doors and is protected by utility patent.

The smoke protection curtain prevents smoke penetrating the lift shaft.

Dimensions

Door design (steel, double skin)     Door width Door height
Centre-opening 2-panel S-2-Z 700 - 1700 mm 2000 - 3000 mm
Side opening 2-panel S-2-R/L 700 - 1700 mm 2000 - 3000 mm
Centre-opening 4-panel S-4-Z 700 - 2780 mm 2000 - 3000 mm
Side opening 3-panel S-3-R/L 700 - 2000 mm 2000 - 3000 mm
Centre-opening 6-panel S-6-Z 1050 - 3500 mm 2000 - 3000 mm

Dimensions

Door design (steel, double skin)     Door width Door height
Centre-opening 2-panel S-2-Z 700 - 1500 mm 2000 - 2445 mm
Side opening 2-panel S-2-R/L 700 - 1500 mm 2000 - 2445 mm
Centre-opening 4-panel S-4-Z 700 - 2780 mm 2000 - 2445 mm
Side opening 3-panel S-3-R/L 700 - 1800 mm 2000 - 2445 mm
Centre-opening 6-panel S-6-Z 1050 - 3300 mm 2000 - 2445 mm


Intermediate sizes and other dimensions available on request.
